Getting Started

Make installation and operation of your controllers quick and easy using the Sonitrol CORE Setup App. You can configure the network settings to establish remote communication to Sonitrol CORE, input and output testing both locally and end-to-end.

Download the app for free on your phone from the App Store or Google Play .

Note: Configuring S1000 using Sonitrol CORE Setup App is not applicable for UL 294 and UL 2610.

You need a phone running

  • Android 12 or higher

  • iOS 13 or higher

Note: Currently, the Sonitrol CORE Setup App is supported only on iPhones and Android phones. iPads, Android tablets, and other mobile devices are currently not supported.
  1. Tap the Setup App on your device.

  2. Tap Search nearby devices.

    The app scans all the available S1000 Controllers in the immediate vicinity.

  3. Tap the listed S1000 Controller you wish to configure.

  4. When prompted, enter the User ID as "1" and Password as "2405" and tap Log In.

    If the controller has any preconfigured values, tap Yes when prompted to download the configurations.

  1. Tap at the top right corner of the screen.

  2. Tap Disconnect device.

    The device is disconnected from the app.
